Details
The dual-sport DXTs are pumped-up, go-anywhere/do-anything versions of a fitness bike, with more gearing range to take on steeper hills and tougher terrain, as well as wider tires with a trail-capable tread for access to more riding areas, both paved and packed. Disc brakes and suspension forks add real off-road exploration and off-pavement adventure.
Specs
Frame | Size Specific Design Triple-butted 6061 aluminum with fast back rear triangle, 1 1/8" head tube, internal cable routing, oval chain stays with post mount disc brake with kickstand mount, 34.9mm seat tube, replaceable derailleur hanger and fender/rack eyelets |
---|---|
Fork | SR/Suntour NVX HLO, aluminum lowers, coil spring, 28mm stanchions, 1-1/8" steerer, aluminum crown, hydraulic lock out, 75mm travel |
Headset | FSA Internal cup, threadless 1 1/8" |
Rims/Wheels | WTB STX i23 TCS (UST Tubeless Compliant System) disc rims, 32H, Joytec disc hubs and 14g stainless steel spokes |
Tires | CST Dual Sport Tire, 700 x 42c |
Crankset | SAMOX Alloy forged crank with 32T steel chainring(BCD104), 170mm |
Bottom Bracket | FSA sealed cartridge, 68 x 110.5mm |
Chain | KMC Z9 |
Rear Derailleur | MicroShift Advent Active Motion RD+ with clutch real deraillier |
Cassette/Rear Cogs | MicroShift 9-speed, 11-42Twith |
Shifters | MicroShift Advent Xpress shifter with bearing, 9-speed |
Handlebars | Jamis Riser bar, 6061 double-butted aluminum, 31.8 x 20mm rise x 10° sweep x 640mm (14-18"), 660mm (20") |
Tape/Grips | Anatomic double density kraton grip with gel |
Stem | Jamis Trekking, 3D forged alloy, 10° rise, 90mm |
Brakes | Tektro HD-276 hydraulic disc brakes with 83mm reach, 160mm rotors and Tektro brake levers. |
Pedals | Full alloy platform, toe clip attachable |
Saddle | Selle Royal Vivo ERGO Femme |
Seat Post | Jamis alloy micro-adjust, 31.6 x 350mm alloy clamp with QR seatpin |
* Subject to change without notice.
Part Numbers
Option | UPC | MPN | Store SKU |
---|---|---|---|
Ano Deep Blue / 20-inch | 845436081038 | 03-3381BL | 210000046568 |
