Details
RIDE POSITION
A usual complaint from new riders trying to get into the cycling groove is feeling uncomfortably perched forward with too much weight on their wrists and having to crank their necks backwards just to be able to see in traffic. We specifically design our Explorers to remedy this. With extra-long head tubes to push handlebar height up, shorter top tubes to pull handlebars closer to the saddle, 4-inch rise handlebars that sweep back at a natural hand-grasp angle, and long-quilled or angle-adjustable stems that allow for a wide range of adjustment to tune handle bar height and reach perfectly for each rider.
COMFORT SADDLE
Our super-plush saddle features memory foam padding (Explorer Sport) or extra high-quality polyurethane padding (Explorer) for optimum support with maximum comfort. The slip-resistant suede-type top prevents sliding and the burnished side panels reduce leg friction while pedaling. Elastomer springs also help to soak up road vibrations. Offered in gender specific sizes.
PUMP UP THE VOLUME
Our Explorer tires are ready for anything; they roll smoothly on pavement but offer a large 2.1” footprint and side knobs so that traction off the beaten path is never an issue. The additional benefit of that big footprint is larger air volume in the tire and tube, which results in lower air pressure for a more comfortable ride than tires with smaller volumes and higher air pressures.
VERSATILITY
But don’t let all this comfort talk fool you into thinking the Explorer has limited uses. While conceived to make cycling as comfortably fun as possible, the Explorer is capable of doing much more than keeping a new rider from hurting. Thanks to the full-range gearing of the drivetrain, the 2.1” footprint of the tires and the shock absorption of the suspension fork.
Specs
Frame | 6061 TIG-welded aluminum, all-new sport comfort design with upright ride position, replaceable derailleur hanger, center-mount kickstand bracket |
---|---|
Fork | SR Suntour XCE 27.5", coil spring, external preload adjustor, 28mm stanchions, aluminum lowers, 80mm travel |
Headset | Internal cup, threaded, 1 1/8” |
Rims/Wheels | Double-wall alloy rims, 32H, alloy hubs with QR |
Spokes | 14g stainless steel |
Tires | CST - 1918, 27.5 x 2.1 |
Crankset | Shimano TY701 alloy crank, 170mm crank length, with chainguard |
Chainrings | 48/38/28T |
Bottom Bracket | Sealed cartridge, 68 x 110.5mm |
Chain | KMC Z7 |
Front Derailleur | Shimano TY710 31.8mm top swing/dual pull |
Rear Derailleur | Shimano TX-800 rear |
Cassette/Rear Cogs | Shimano HG20, 8-speed, 12-32 |
Shifters | Shimano EZ-Fire Plus, ST-EF510, 24-speed |
Handlebars | Hi-rise comfort, 15D sweep x 80mm rise x 640mm wide |
Tape/Grips | Kraton comfort |
Stem | Jamis alloy, angle-adjustable, 90mm ext x 150mm quill (14–18") or 110mm ext x 180mm quill (19–21”) |
Brake Levers | Shimano |
Brakes | Tektro forged alloy direct pull brakes |
Pedals | Comfort platform with TPE non-slip insert |
Saddle | Jamis Comfort with memory foam, synthetic suede top, burnished side panels and bumper springs |
Seat Post | Suspension, alloy micro-adjust, 350mm x 27.2mm, with alloy QR clamp |
* Subject to change without notice.
Part Numbers
Option | UPC | MPN | Store SKU |
---|---|---|---|
Ano Palladium / 15-inch | 845436076300 | 03-3044PD | |
Ano Palladium / 17-inch | 845436076324 | 03-3046PD | |
Ano Palladium / 19-inch | 845436076348 | 03-3048PD | |
Ano Palladium / 21-inch | 845436076362 | 03-3050PD | |
Riptide / 15-inch | 845436082301 | 03-3509BL | |
Riptide / 17-inch | 845436082318 | 03-3510BL | 210000047713 |
Riptide / 19-inch | 845436082325 | 03-3511BL | |
Riptide / 21-inch | 845436082332 | 03-3512BL |
